| Seat Height Range | 5’0” - 6’2” |
| Weight Capacity | 280 lbs. |
| Maximum Loaded Weight | 153 lbs. |
| Seat Depth Range (From Seat Pivot) | 18” - 23” |
| Seat-to-Footplate Range (From Seat Pivot) | 14” - 21” |
| Knee Width (Center to Center) | 9” |
| Kneepad Depth Range (From Seat Pivot) | 2” - 7” |
| Seat Height | 21.5” |
| Seat Dimensions | 19” W x 21.5” D |
| Standard Tray Size | 21” x 24” |
| Tray/Chest Pad Depth Range (From Seat Pivot) | 0” - 10.5” |
| Standard Tray Height Range (From Seat Pivot) | 15.5” - 30.5” |
| Overall Footprint (Widest Points) | 26.5” x 33.5” |
| Weight of Basic Unit | 104 lbs |
| Frame Color | Charcoal |
| Standard Upholstery Color | Black |
| Locking Caster Diameter | 5” |
| Footplate Plantar Flexion Adjustment | 10° (3 Increments) |
| Footplate Dorsiflexion Adjustment | 10° (3 Increments) |
| Footplate Toe-Out Adjustment | 15° (3 Increments) |
| Shadow Tray Height From Seat | 12.25” (Acrylic Tray is 1” Shorter) |
| Weight of Evolv with Shadow Tray | 115 lbs. |
| Shadow Tray Size | 21” x 24” |
90-Day Warranty From Open Box Medical
If, for some reason, you are encountering problems with the medical equipment you purchased, you must first contact us by calling (818) 896-8772. If the purchased item is being used within our service area, we will schedule an appointment to send out a repair technician as soon as possible to diagnose the issue and determine whether it can be fixed or not. If the item is not in our service area, depending on the location, we will either be able to send out a repair technician or have you ship the item back to us. The warranty is void if the item's ownership is transferred to a new owner, if the item is damaged due to misuse, accident, or normal wear and tear, or if the equipment is used in any way that would void the original manufacturer's warranty. For more information about our warranty, please contact us by calling (818) 896-8772 during our normal business hours.
